XUYF954015COS

Telemecanique Photoelectric sensors XU

Application

Photo-electric sensor

XUY

Fork

Thru beam

Infrared, continuous

DC

4-wire

PNP/NPN

Control of tools travel
detection of marks on a translucent film
detection of sheets overlapping
detection on a labelling machine
lateral shift control of a belt
lift cage position control

Painted aluminium strong housing

Discrete

Solid state

<1 V at 10 mA (closed state), <2 V at 100 mA (closed state)

12...24 V DC with reverse polarity protection

40 mA no-load

100 mA (overload and short-circuit protection)

IP65 conforming to IEC 60529

PCE

1
