XS1M30MB250L1

Inductive proximity sensors XS, inductive sensor XS1 M30, L60mm, brass, Sn10mm, 24...240VAC/DC, cable 5 m

End of commercialisation Datum der Produktabkündigung : Datum des Service-Endes :

pdf-Datenblatt herunterladen 3d cad-Datei herunterladen Fachhändler in der Nähe

XS1M30MB250L1 is replaced by the following product:

XS1M30MB250K

Inductive proximity sensors XS, inductive sensor XS1 M30, L72mm, brass, Sn10mm, 24...240VAC/DC, 1/2"

Menge 1

XZCPV1865L5

Pre wired connectors XZ, straight female, 1/2"20 UNF, 3 pins, cable PVC 5 m

Menge 1

Merkmale
Technische Zeichnungen
Dokumente & Downloads

Alle erweitern

Datenblatt

Range of product

Telemecanique Inductive proximity sensors XS

Series name

General purpose

Sensor type

Inductive proximity sensor

Wiring configuration

2-wire

Sensor name

XS1

Device application

2-wire DC short-circuit protection

Sensor design

Cylindrical M30

Protection type

Short-circuit protection multi voltage

Size

60 mm

Body type

Fixed

Type of output signal

Discrete

Wiring technique

2-wire

Discrete output function

1 NC

Detector flush mounting acceptance

Flush mountable

Material

Metal

Electrical connection

Cable

[Us] rated supply voltage

24...210 V DC, 24...240 V AC 50/60 Hz

Output circuit type

AC/DC

Switching capacity in mA

5...300 mA AC with overload and short-circuit protection, 5...200 mA DC with overload and short-circuit protection

IP degree of protection

IP68 double insulation conforming to IEC 60529

Enclosure material

Nickel plated brass

Detection face

Frontal

Thread type

M30 x 1.5

Front material

PPS

Sensing range

8...15 mm

Differential travel

1...15 % of Sr

Cable composition

2 x 0.34 mm²

Residual current

1.5 mA open state

Status LED

Output state: 1 LED (yellow), supply on: 1 LED (green)

Wire insulation material

PVC

Switching frequency

<= 2000 Hz DC, <= 25 Hz AC

Voltage drop

<5.5 V (closed state)

Delay first up

70 MILLISECOND

Delay response

2 MILLISECOND

Marking

Delay recovery

5 MILLISECOND

Product certifications

CCC
CSA
UL

Vibration resistance

25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6

Shock resistance

50 gn for 11 ms conforming to IEC 60068-2-7

Unit type of package 1

PCE

Number of units in package 1

Package 1 height

8 CENTIMETER

Package 1 width

8 CENTIMETER

Package 1 length

14.8 CENTIMETER

Package 1 weight

335 GRAM

California proposition 65

WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
