XSDA605539

Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn40mm, 24...240 VAC, terminals

arrow

Commercialised

Download pdf datasheet Download 3d cad file Find a distributor

Expand all

Datasheet

Range of product
Telemecanique Inductive proximity sensors XS
Series name
General purpose
Sensor type
Inductive proximity sensor
Sensor name
XSD
Sensor design
Form 80 x 80 x 40
Size
40 mm
Body type
Fixed
Enclosure material
Plastic
Type of output signal
Discrete
Wiring technique
2-wire
Discrete output function
1 NO or 1 NC programmable
Electrical connection
Screw-clamp terminals
[Us] rated supply voltage
132 V AC
IP degree of protection
IP67
Detector flush mounting acceptance
Non flush mountable
Material
Plastic
Output circuit type
AC
Detection face
5 positions turret head
Front material
Plastic
Cable entry
1 entry tapped for Pg 13.5 cable gland
Sensing range
> 40...60 mm
Switching frequency
<= 10 Hz
Product certifications
CCC
Unit type of package 1
PCE
Number of units in package 1
1
Package 2 height
15 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
2.75 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
