Datasheet
Technical Drawings
(1) 2 fixing holes Ø 4.2 mm, counterbored Ø 8 mm by 4 mm deep.
Plunger or Multi-directional Heads
Single-pole CO Snap Action + Integral M12 4-pin Connector
4-pin, M12, 3A-250V
1 : Common
2 : NC
3 : Grounding
4 : NO
Switch Actuation on End
(P) Positive opening point
(1) Closed
(2) Open
(4) Tripping
(5) Resetting
