XS7E1A1DAL01M12
Inductive proximity sensors XS, inductive sensor XS7 26x26x13, PBT, Sn10mm, 12...24 VDC, M12 0.15 m
Commercialized
Expand all
Datasheet
Range of product
Telemecanique Inductive proximity sensors XS
Series name
General purpose
Sensor type
Inductive proximity sensor
Device application
-
Sensor name
XS7
Sensor design
Flat form 26 x 26 x 13
Size
13 mm
Body type
Fixed
Detector flush mounting acceptance
Flush mountable
Material
Plastic
Enclosure material
PBT
Type of output signal
Discrete
Wiring technique
2-wire
Discrete output function
1 NO
Output circuit type
DC
Electrical connection
Remote male connector M12, 4 pins
Cable length
0.15 m
[Us] rated supply voltage
12...24 V DC with reverse polarity protection
Switching capacity in mA
1.5...100 mA DC with overload and short-circuit protection
IP degree of protection
IP67 double insulation conforming to IEC 60529
Detection face
Frontal
Front material
PBT
Operating zone
0…8 mm
Differential travel
1...15% of Sr
Wire insulation material
PVC
Status LED
Output state: 1 LED (yellow)
Supply voltage limits
10…36 V DC
Maximum residual current
0.5 mA open state
Switching frequency
<= 1000 Hz
Maximum voltage drop
<4 V (closed)
Maximum delay first up
5 ms
Maximum delay response
0.3 ms
Maximum delay recovery
0.7 ms
Marking
CE
Depth
13 mm
Height
26 mm
Width
26 mm
Net weight
0.04 kg
Product certifications
C-Tick
CSA
Ecolab
UL
CSA
Ecolab
UL
Ambient air temperature for operation
-25…70 °C
Ambient air temperature for storage
-40…85 °C
Vibration resistance
25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
Shock resistance
50 gn for 11 ms conforming to IEC 60068-2-27
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
4.2 cm
Package 1 Width
9.5 cm
Package 1 Length
6.6 cm
Package 1 Weight
53.0 g
Unit Type of Package 2
S02
Number of Units in Package 2
22
Package 2 Height
15 cm
Package 2 Width
30 cm
Package 2 Length
40 cm
Package 2 Weight
1.648 kg
Unit Type of Package 3
P06
Number of Units in Package 3
352
Package 3 Height
105 cm
Package 3 Width
60 cm
Package 3 Length
80 cm
Package 3 Weight
27.156 kg
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury free
Yes
RoHS exemption information
Circularity Profile
No need of specific recycling operations
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
Expand all
Technical Drawings
Dimensions
(1) LED
(2) For CHC type screws
Setting-up
Minimum Mounting Distances (mm)
Minimum Mounting Distances (mm)
Minimum Mounting Distances (mm)
Side by Side
e (1) ≥ 30
Face to Face
e (2) ≥ 72
Facing a Metal Object
e (3) ≥ 30
Wiring Schemes
2-Wire NO
2-Wire NO
M12
