XZCC12FDM50B
Female, M12, 5 pin, straight connector, cable gland Pg 7
Commercialized
Expand all
Datasheet
Range of product
Telemecanique Cabling components
Accessory / separate part category
Cabling accessories
Accessory / separate part type
Connector
Electrical connection
Straight female connector M12, 5 pins
Collar material
Metal
Status LED
Without
Cable connection
Screw terminal / wire size <0.75 mm² / clamping capacity 3…6 mm
Cable gland type
Pg 7
Cable connector fixing
Screw-on
[Ue] rated operational voltage
30 V AC
36 V DC
36 V DC
[In] rated current
3 A
Enclosure material
Plastic
Minimum insulating resistance
1000 GΩ
Contact resistance
8000 µOhm
Net weight
0.02 kg
IP degree of protection
IP67
Ambient air temperature for operation
-40…85 °C
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
2.000 cm
Package 1 Width
5.500 cm
Package 1 Length
11.500 cm
Package 1 Weight
27.000 g
Unit Type of Package 2
S02
Number of Units in Package 2
50
Package 2 Height
15.000 cm
Package 2 Width
30.000 cm
Package 2 Length
40.000 cm
Package 2 Weight
1.710 kg
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury free
Yes
RoHS exemption information
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
Expand all
Technical Drawings
Dimensions
- (1) Cable gland : no. 7 plastic (Pg 7)
