9007AO2
Snap switch 9007A, 600 VAC, 15 A, option version
COMMERCIALISED
Expand all
Datasheet
Range of product
9007
Series name
Heavy duty
Product or component type
Snap basic limit switch
Device short name
9007AO/CO
Body type
Fixed
Mounting mode
Not applicable
Operator profile
Plunger head
Body material
Cast zinc
Material
Metal
Operator material
Cast zinc
Fixing mode
By the body
Movement of operating head
Linear
Type of operator
Spring return plunger plastic with thermoplastic end
Switch actuation
On end
Type of approach
Vertical approach, 1 direction
Electrical connection
1-2 cables for 6 binder head screw terminals (AWG 22...AWG 14)
Contact operation
Snap action
Contacts material
Silver contacts
Contacts type and composition
NC-NO, switch function: SPDT-DB
Contact form
Form Z
Positive opening
Without
Terminals description ISO n°1
(1-2)NC
(3-4)NO
(3-4)NO
NEMA degree of protection
NEMA 1 conforming to Nema type 250
IP degree of protection
IP20 conforming to IEC 60529
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.8 CENTIMETER
Package 1 width
10.2 CENTIMETER
Package 1 length
15.2 CENTIMETER
Package 1 weight
0.0408 KILOGRAM
Unit type of package 2
S01
Number of units in package 2
50
Package 2 height
15 CENTIMETER
Package 2 width
15 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
2.225 KILOGRAM
Unit type of package 3
S02
Number of units in package 3
100
Package 3 height
15 CENTIMETER
Package 3 width
40 CENTIMETER
Package 3 length
30 CENTIMETER
Package 3 weight
4.555 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
