Home Products 9007CB41

9007CB41

Snap switch 9007A, option version

arrow

COMMERCIALISED

Download pdf datasheet Download 3d cad file Find a distributor

Expand all

Datasheet

Range of product
9007
Series name
Heavy duty
Product or component type
Snap limit switch
Device short name
9007AO/CO
Body type
Fixed
Mounting mode
Not applicable
Operator profile
Plunger head
Material
Metal
Body material
Cast zinc
Operator material
Cast zinc
Fixing mode
By the body
Movement of operating head
Linear
Type of operator
Spring return roller lever plunger metal no bracket + 0.22" roller
Switch actuation
By 30° cam
Type of approach
Traverse approach, 2 directions
Electrical connection
1-2 cables for 6 binder head screw terminals (AWG 22...AWG 14)
Contact operation
Snap action
Contacts type and composition
2(NC-NO), switch function: DPDT-DB
Contact form
Form ZZ
Contacts material
Silver contacts
Positive opening
Without
Terminals description ISO n°1
(1-2)NC
(3-4)NO
(5-6)NC
(7-8)NO
NEMA degree of protection
NEMA 1 conforming to Nema type 250
IP degree of protection
IP20 conforming to IEC 60529
Unit type of package 1
PCE
Package 1 height
6.452 CENTIMETER
Number of units in package 1
1
Package 1 width
2.54 CENTIMETER
Package 1 length
16.387 CENTIMETER
Package 1 weight
680.389 GRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Expand all

Documents & Downloads

Document name
Date
Size
Catalogue for limit switches, Range 9007 (pdf)

2024-10-31

18760251

Document name
Date
Size
NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dxf)

2024-07-18T00:00:00.000Z

122647

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dwg)

2024-07-18T00:00:00.000Z

20793

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dwg)

2024-07-18T00:00:00.000Z

21050

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dwg)

2024-07-18T00:00:00.000Z

21273

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dwg)

2024-07-18T00:00:00.000Z

21562

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dwg)

2024-07-18T00:00:00.000Z

21589

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dwg)

2024-07-18T00:00:00.000Z

21725

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dxf)

2024-07-18T00:00:00.000Z

21836

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dxf)

2024-07-18T00:00:00.000Z

23929

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dxf)

2024-07-18T00:00:00.000Z

24042

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dxf)

2024-07-18T00:00:00.000Z

25160

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dxf)

2024-07-18T00:00:00.000Z

26089

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dxf)

2024-07-18T00:00:00.000Z

26411

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (stp)

2024-07-18T00:00:00.000Z

329901

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (pdf)

2024-07-18

37001

NEMA Square D 9007 Limit Switches, 9007 AO/CO Heavy Duty Snap Switches, Plastic plunger with rigid metal roller lever, without side mount bracket, 9007 AO/CO Snap Switch Plastic plunger, metal roller lever, no mounting bracket - 3D CAD (dwg)

2024-07-18T00:00:00.000Z

48828

Document name
Date
Size
TESEDEC0000EN_PFAS_Global_Declaration_for_9007CB41 (pdf)

2026-08-19

277696

TESEDEC0000EN_REACh_Declaration_for_9007CB41 (pdf)

2026-06-05

109709

TESEDEC0000EN_RoHS_Declaration_for_9007CB41 (pdf)

2026-06-05

109323
