Mechanical durability
10000000 cycles
Electrical durability
100000 cycles
Electrical connection
Pre-wired cable side
Wire insulation material
PVC
Contacts type and composition
NC-NO
Contacts material
Silver contacts
Terminals description ISO n°1
(black)com
(green-yellow)gnd
(red)NC
(white)NO
Contact operation
Snap action
[Ui] rated insulation voltage
300 V (pollution degree 3) conforming to UL 508, 300 V (pollution degree 3) conforming to CSA C22.2 No 14
[Ie] rated operational current
6 A at 120 V AC, A300 conforming to NEMA rating designation, 3 A at 240 V AC, A300 conforming to NEMA rating designation, 5 A at 28 V DC
[Ithe] conventional enclosed thermal current
10 A
Type of cable
SJTO cable (AWG 18), 18 ft, yellow
