9007MS12S0054

Limit switch 9007 MS/ML, parallel roller plunger, M12 DC, 240 VAC, 10 A

arrow

COMMERCIALISED

Expand all

Datasheet

Range of product
9007
Series name
Miniature potted
Product or component type
Limit switch
Device short name
9007MS/ML
Sensor design
Miniature
ETIM classification
ETIM 9 - EC000030 - End switch
Body type
Fixed
Head type
Plunger head
Material
Metal
Body material
Cast zinc
Fixing mode
By the body
Movement of operating head
Linear
Type of operator
Spring return parallel roller plunger steel booted
Switch actuation
By 30° cam
Type of approach
Lateral approach, 2 directions
Maximum force for tripping
80 ozf
Number of poles
1
Product certifications
CE
CSA
UL
Marking
CE
CSA
UL
Standards
E78403
LR 25490 Class 32 11 03
Indivisible sale quantity
1
Sale per indivisible quantity
1
Mechanical durability
10000000 cycles
Electrical durability
100000 cycles
Electrical connection
Male connector M12 micro DC type 4 pins bottom
Positive opening
Without
Contact form
Form C
Contacts type and composition
NC-NO
Contacts material
Silver contacts
Terminals description ISO n°1
(1)gnd
(2-4)NO
(3-4)NC
Contact operation
Snap action
[Ui] rated insulation voltage
300 V (pollution degree 3) conforming to UL 508, 300 V (pollution degree 3) conforming to CSA C22.2 No 14
[Ie] rated operational current
3 A at 28 V DC, 3 A at 120 V AC, 3 A at 240 V AC
[Ithe] conventional enclosed thermal current
3 A
Switch function
SPDT
Width
1.56 in
Depth
0.62 in
Product weight
1.2 livre
IP degree of protection
IP67 conforming to IEC 60529
NEMA degree of protection
NEMA 1 conforming to Nema type 250, NEMA 2 conforming to Nema type 250, NEMA 4 conforming to Nema type 250, NEMA 6 conforming to Nema type 250, NEMA 6P conforming to Nema type 250
Ambient air temperature for operation
-40…104 °C
Ambient air temperature for storage
-40…104 °C
Shock resistance
35 gn for 9 ms conforming to IEC 60068-2-27
Vibration resistance
10 gn (f= 75-1200 Hz) conforming to IEC 60068-2-6
Protective treatment
Epoxy powder coat
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
Country of origin
MX (Mexico)
Unit type of package 1
PCE
Number of units in package 1
1
New Package 1 GTIN-13
3666916095898
Package 1 height
4.572 cm
Package 1 width
5.334 cm
Package 1 length
9.144 cm
Package 1 weight
544.311 g
New Package 2 GTIN 14
13666916095895
New Package 3 GTIN 14
23666916095892
