XMLG006D23

Telemecanique Pressure sensors XM

Electronic pressure sensors

Pressure transmitter

XMLG

1/4" - 18 NPT (male)

Air (-15-125 °C), corrosive fluid (-15-125 °C), hydraulic oil (-15-125 °C), fresh water (0-125 °C)

Analogue

4...20 mA, 2 wires

1 male connector M12, 3 pins

12 V DC (voltage limits: 8-33 V), 24 V DC (voltage limits: 8-33 V)

Set of 1

Individual

Without

Control circuit

20 mA

Ceramic
FPM (Viton)
stainless steel type AISI 303

Any position

Load short-circuit
reverse polarity

< 2 ms

+/- 0.015 % of measuring range/°C

+/- 0.015 % of measuring range/°C

+/- 0.3 % of the measuring range

+/- 0.1 % of the measuring range

CE
IEC 61326-2-3

CSA C22-2 No 14
UL 508

TC

20 gn (f= 9-2000 Hz) conforming to IEC 60028-2-6

25 gn for 11 ms conforming to IEC 60068-2-27

IP66 conforming to IEC 60529, IP67 conforming to IEC 60529

NEMA 4

PCE

1

5 CENTIMETER

10.5 CENTIMETER

13.5 CENTIMETER

0.135 KILOGRAM

1
