9007A

Limit switch head for 9007C, lever-arm head

arrow

COMMERCIALISED

Expand all

Datasheet

Range of product
9007
Series name
Heavy duty
Product or component type
Limit switch head
Device short name
9007C
ETIM classification
ETIM 9 - EC000030 - End switch
Head type
Rotary head
Movement of operating head
Rotary
Type of operator
Spring return without operating lever zinc low differential
Switch actuation
CW and CCW
from left and right
Type of approach
Lateral approach, 1 or 2 programmable direction
Product compatibility
9007C
Indivisible sale quantity
1
Positive opening
Without
Product weight
0.41 livre
Environmental characteristic
Standard environment
Ambient air temperature for operation
-29…85 °C
Ambient air temperature for storage
-29…85 °C
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
Country of origin
MX (Mexico)
Unit type of package 1
PCE
Number of units in package 1
1
New Package 1 GTIN-13
3666916091272
Package 1 height
4.6 cm
Package 1 width
4.8 cm
Package 1 length
7.6 cm
Package 1 weight
190.5 g
New Package 2 GTIN 14
13666916091279
New Package 3 GTIN 14
23666916091276
